| 起源の場所: | 中国 |
|---|---|
| ブランド名: | SAFEGAS |
| 証明: | ATEX/IECEX |
| モデル番号: | SG100 |
| 最小注文数量: | 1 |
| 価格: | 交渉可能 |
| パッケージの詳細: | アルミニウムスーツケースパッキング |
| 受渡し時間: | 3-5営業日 |
| 支払条件: | T/T、ウェスタンユニオン |
| 供給の能力: | 100個/日 |
| 検出されたガス: | 毒性ガス,酸素,燃やす気体,VOCガス | 検出原理: | 電気化学,NDIR,触媒,PIDなど |
|---|---|---|---|
| 電力散逸: | 有毒ガス<2.5W、可燃性ガス<4W | 通信モード: | 4-20MA（3線）、RS485 1〜5V、ハート（オプション） |
| 無線: | ロラ、4G（オプション） | 作業電圧: | 12-24VDC |
| リレー: | 低/高/断層アラームリレーを含む3リレー（オプション） | 画面: | LEDディスプレイ |
| 作業温度: | -40 ℃〜70℃（触媒センサー）、-20℃〜50℃（電気化学センサー） | 作業圧力: | 86kPa~106kPa |
| ケーシング材料: | オプションのためのダイカストアルミニウム、S316 | ケーブル入口: | 1x¾NPT＆1 x M20ケーブルエントリ接続 |
| サイズ: | 157.8×128.8×69.6mm | 重さ: | 1.0kg |
| 保証: | 1年 | ||
| ハイライト: | cost-effective flammable gas detector,IP66 waterproof gas detector,dust resistant multi gas detector |
||
| Gas Detected | Toxic gases, oxygen, flammable, VOC gases |
|---|---|
| Detection Principle | Electrochemical, NDIR, Catalytic, PID, etc |
| Measure range | Specified according to application |
| Resolution | Specified according to application |
| Accuracy | ≤±2-5%FS (Depending on the specific sensor) |
| Explosion-proof grade | IECEx: Ex db IIC T6 Gb, Ex db ia IIC T6 Gb; ATEX: Ex db IIC T6 Gb, Ex db ia IIC T6 Gb |
| Protection grade | IP66/68 |
| Power dissipation | Toxic gas<2.5W, flammable gas<4W |
| Communication mode | 4-20mA (3-wires),RS485 1~5V, Hart (Optional) |
| Wireless | LORA, 4G (Optional) |
| Working voltage | 12-24VDC |
| Relay | 3 relays, including low/high/fault alarm relay (Optional) |
| Display | LED display |
| Working temperature | -40℃~70℃ (Catalytic sensor), -20℃~50℃ (Electrochemistry sensor) |
| Working pressure | 86kPa~106kPa |
| Casing material | Die casting aluminum, S316 for option |
| Cable Entries | 1 x ¾ NPT & 1 x M20 Cable Entry Connections |
| Size | 157.8×128.8×69.6mm |
| Weight | 1.0Kg |
| Warranty | 1 year |
Gas Detection CapabilitiesCompany ProfileEstablished in 2010, Shenzhen Yuante Technology Co., Limited is a company that focuses on the design, production and sales of high-end gas detection equipment and system for 16 years. With gas detector as the core product, we have completed production line and solutions according to different industries, such as Oil, Chemical, Medicine, Energy, Environmental Protection, Electronic,Municipal Engineering, Agriculture and Forestry, Household Appliances, etc. Through about 10 years of rapid development, Yuante becomes the influential supplier.
For years, Yuante always insists on the management concept Market is orientation; Innovation is motivation; Quality to survival; Development to growth. With friendly, open and strict corporate culture and standardized management, Yuante gathers a lot of talents, and builds up the management team and R&D team. All the staff cooperates well in product development, production and maintenance, and has a deep understanding of the concept of customer oriented and has the service spirit through the company operation and management, to win the trust and support from customers.
The essence of a detector is the accuracy and faster response. Depending on years of measurement experience and unique solutions, through independent research and development, cooperative development and learning overseas latest technology, Yuante's products are advanced beyond the domestic brands and ahead of the global brands. We are seeking for development and progress constantly, and trying to meet diversified demands from customers.
