| 起源の場所: | 中国 |
|---|---|
| ブランド名: | SAFEGAS |
| 証明: | ATEX/EMC/IECEX |
| モデル番号: | Sky3000 |
| 最小注文数量: | 1 |
| 価格: | 交渉可能 |
| パッケージの詳細: | アルミニウムスーツケース |
| 受渡し時間: | 3営業日 |
| 支払条件: | T/T、ウェスタンユニオン |
| 供給の能力: | 1か月あたり1000個 |
| ガス: | ヱト | 測定範囲: | 0-100ppm |
|---|---|---|---|
| 解決: | 0.1ppm | センサーの種類: | 電気化学 |
| サンプリング方法: | ポンプ吸引 | 証明: | CE,ATEX,IECEx,ISO |
| 言語: | 中国/英語/ロシア語/カスタマイズ | アラームモード: | バザー,LED,振動 |
| 力: | 3.7V充電可能なリチウムバッテリー | 勤務時間: | 15時間以上 (ポンプが動いている場合) |
| データレコード: | 100000セットのデータを保存できます | 単一パッケージのサイズ:: | 34cm*24cm*14cm |
| 単一の総体重：: | 1.64kg | 保護等級: | IP67 |
| Parameter | Specification |
|---|---|
| Sampling method | Pump suction |
| Gas type | Specified according to application |
| Measure range | Specified according to application |
| Resolution | Specified according to application |
| Response time | ≤10 seconds |
| Precision | ≤±1% F.S |
| Language | English (Other languages customizable) |
| Automatic functions | Reset, maximum value (MAX), minimum value (MIN), STEL, TWA value |
| Unit | PPM and mg/m³ switchable |
| Display | Monochrome graphics (160 x 96), automatic screen flip |
| Backlight | Manually settable time, automatic on during alarm |
| Data record | 100,000 data sets, adjustable storage interval 5-3600 seconds, data exportable |
| Alarm | 95dB buzzer, vibration, flashing red LED, screen indication, diagnostic alarm, battery undervoltage, pump block, man down alarm with Bluetooth notification |
| Battery | 3.7V rechargeable lithium battery, 2200mA capacity |
| Working hours | More than 15 hours continuous pumping |
| Charger | Travel charger with DC interface, ≥4 hours charging time |
| Explosion-proof grade | IECEX/ATEX (II IG Ex ia IIC T4), CNEX: Ex ia IIC T4 Ga |
| Certification (EU) | 2004/108/EC (EMC), 1995/5/EC (Radio), 94/9/EC (ATEX) |
| Protection grade | IP67/IP68 |
| Working temperature | -20ºC to +50ºC |
| Humidity | 0-90% RH (no condensation) |
| Environmental pressure | 86-106 Kpa |
| Size | 157 × 84.5 × 59.5mm (including accessories) |
| Weight | 365g (including battery and accessories) |
| Bluetooth function (Optional) | Real-time data transmission to mobile phone or PC |
