| 起源の場所: | 中国 |
|---|---|
| ブランド名: | Safegas |
| 証明: | CE/ATEX |
| モデル番号: | YT-1200H-S |
| 書類: | YT-1200H-S Datasheet.pdf |
| 最小注文数量: | 1 |
| 価格: | 交渉可能 |
| パッケージの詳細: | カートン |
| 受渡し時間: | 3営業日 |
| 支払条件: | T/T |
| 供給の能力: | 100個/日 |
| 検出されたガス: | VOC | 検出原理: | 拡散 |
|---|---|---|---|
| センサーの種類: | PID | 精度: | <1～5% FS |
| バックライト: | 設定可能時間アラーム中に自動オン | 言語: | 中国語/英語 |
| アラームの種類: | 音、軽い、振動 | 保護等級: | IP65 |
| 防爆グレード: | 前のia IIC T4 |
Portable Diffusion Gas Detector for VOC (PID)
A mini-sized, low-cost, high-accuracy portable diffusion gas detector for VOC monitoring. Measures 0–100ppm with 0.01ppm resolution using a PID sensor. Features IP65 protection, Ex ia IIC T4 explosion-proof rating, triple alarm (ultra-high buzzer + light + vibration), 2500mAh rechargeable battery (14h runtime with 4 gases), standard event logging (100 records), and optional data logging (100,000 readings). Ideal for industrial hygiene, leak detection, and indoor air quality.
| Parameter | Value |
|---|---|
| Gas Detected | VOC (Volatile Organic Compounds) – user specified |
| Detection Principle | Diffusion |
| Sensor Type | PID (as specified for VOC) |
| Measuring Range | 0 – 100 ppm |
| Resolution | 0.01 ppm |
| Precision | <1–5% F.S. |
| Display | Monochrome dot matrix 128×128 LCD graphic display |
| Backlight | Settable time; auto-on during alarm |
| Data Logging | Optional: 100,000 readings (10–3600 sec interval) |
| Event Logging | 100 event records (standard, viewable on device) |
| Language | Chinese / English |
| Alarm Type | Sound, light, vibration |
| Battery | 3.7V rechargeable lithium battery, 2500mAh |
| Working Time | 14h continuous (common 4 gases); 200h (without LEL sensor) |
| Charger | Travel charger; charging time 4–6h |
| Explosion-Proof Grade | Ex ia IIC T4 |
| Protection Grade | IP65 |
| Working Temperature | 10°C – 50°C |
| Working Humidity | 15 – 95% RH |
| Housing Material | ABS + leather case |
| Dimensions | 131 × 83 × 35 mm |
| Weight | 240g |
The precision is <1–5% F.S.
14 hours continuously (common 4 gases); 200 hours (without LEL sensor).
IP65.
Optional – 100,000 readings, interval 10–3600 seconds, exportable to PC via software.
100 event records, viewable on device.
Ex ia IIC T4.
Yes – one press to restore factory settings.
Chinese and English.
240g.
4–6 hours.
Sound, light, vibration.
Yes – when alarm occurs, the backlight turns on automatically.
10°C to 50°C.
Yes – the detector comes with a back clip and is protected by a silicone case.
Monochrome dot matrix 128×128 LCD graphic display.
Shenzhen YuanTe Technology Co., Ltd. (brand: Safegas) was established in 2010 and specializes in the R&D, manufacturing, and sales of gas detection equipment and integrated systems. With over 16 years of industry expertise, the company serves sectors including oil & gas, chemicals, environmental protection, electronics, municipal engineering, agriculture, and household appliances. All products are manufactured under ISO9001 and ISO45001 management systems, holding international certifications such as IECEx, ATEX, and EMC. With an annual production capacity of over 80,000 units, YuanTe Technology supplies gas detection solutions to customers worldwide.
