| 起源の場所: | 中国 |
|---|---|
| ブランド名: | SAFEGAS |
| 証明: | ATEX/EMC/IECEX |
| モデル番号: | ミニマ |
| 最小注文数量: | 1 |
| 価格: | 交渉可能 |
| パッケージの詳細: | カートン |
| 受渡し時間: | 3営業日 |
| 支払条件: | T/T、ウェスタンユニオン |
| 供給の能力: | 1 か月あたり 3000 個 |
| 検出原理: | 拡散 | 寸法: | 90mm*60mm*33mm (長さ*幅*厚さ) |
|---|---|---|---|
| 検出されたガス: | CL2 | 測定範囲: | 0～10ppm 0～50ppm |
| 解決: | 0.01ppm | 体重 (クリップ付き): | 125g |
| 正確さ: | ≤±2-5％fs | アラームモード: | 音,光,振動アラーム |
| 使用空気圧: | 86〜106kpa | 応答時間（T90）: | 15歳から30歳 |
| 保護クラス: | IP66/68 | 使用温度: | -20 ℃〜55℃ |
| 原理: | 電気化学の主義 | 爆発的な認証: | IECEX、ATEX |
| 動作湿度（非凝縮）: | 0-95%RH | 画面: | ガスの名前,バッテリーの電源,濃度単位,測定値 |
| 電源モード：: | 3.6V乾電池 (充電不能で交換可能) | アラームの種類: | 低アラーム,高アラーム,STEL,TWA,低バッテリーオプション校正のため,および衝突テストのため |
The MiniMeta Portable CL2 Gas Detector is a high-precision portable gas detector designed for chlorine detection using diffusion detection principle, specifically engineered for industrial safety applications in wastewater treatment plants and similar environments.
This IECEX/ATEX/EMC certified single-gas detector can detect hundreds of user-selected toxic gases. User-friendly and easy to operate, it features replaceable battery and sensor for long-term protection, offering a low-cost, long-term ownership gas monitoring system.
| Parameter | Specification |
|---|---|
| Detect gas | CL2 (Chlorine) |
| Sensor type | Electrochemical |
| Sampling method | Diffusion |
| Measure range | 0-10ppm / 0-50ppm |
| Resolution | 0.01ppm |
| Precision | ≤± 3% F.S. |
| Response Time | ≤30s (T90) |
| Display | Gas name, concentration unit, measured value, battery level |
| Alarm mode | Sound, light, vibration alarm |
| Alarm type | Low alarm, high alarm, STEL, TWA, low battery |
| Operating language | Chinese/English |
| Size | 90×60×33mm |
| Weight | 125g |
| Working Temperature | -20ºC to 50ºC |
| Working Humidity | 0-95%RH |
| Working air pressure | 86-106kpa |
Established in 2010, Shenzhen Yuan Te Technology Co., Limited (Safegas) specializes in the design, production, and sales of gas detection equipment and systems. With 16 years of industry experience, we provide comprehensive solutions for various sectors including Oil, Chemical, Medicine, Energy, Environmental Protection, Electronics, Municipal Engineering, Agriculture, and Household Appliances.
