| 起源の場所: | 中国 |
|---|---|
| ブランド名: | SAFEGAS |
| 証明: | ATEX/EMC/IECEX |
| モデル番号: | ミニマ |
| 最小注文数量: | 1 |
| 価格: | 交渉可能 |
| パッケージの詳細: | カートン |
| 受渡し時間: | 3営業日 |
| 支払条件: | T/T、ウェスタンユニオン |
| 供給の能力: | 1 か月あたり 3000 個 |
| 解決: | 0.01ppm | 使用空気圧: | 86〜106kpa |
|---|---|---|---|
| 画面: | ガスの名前,バッテリーの電源,濃度単位,測定値 | 検出されたガス: | NO2 |
| 測定範囲: | 0-100PPM、0-500PPM | 体重 (クリップ付き): | 125g |
| 原理: | 電気化学の主義 | 爆発的な認証: | IECEX、ATEX |
| 寸法: | 90mm*60mm*33mm (長さ*幅*厚さ) | 電源モード：: | 3.6V乾電池 (充電不能で交換可能) |
| 検出原理: | 拡散 | アラームの種類: | 低アラーム,高アラーム,STEL,TWA,低バッテリーオプション校正のため,および衝突テストのため |
| 応答時間（T90）: | 15歳から30歳 | 正確さ: | ≤±2-5％fs |
| 使用温度: | -20 ℃〜55℃ | 動作湿度（非凝縮）: | 0-95%RH |
| アラームモード: | 音,光,振動アラーム | 保護クラス: | IP66/68 |
Portable NO2 Gas Detector IP68 Waterproof Industrial Usage
Minimeta Portable NO2 Gas Detector is a high-precision portable gas detector for nitrogen dioxide detection using diffusion detection principle, designed for industrial safety applications.
MiniMeta is an IECEX/ATEX/EMC certified single-gas detector that can detect hundreds of user-selected toxic gases. User-friendly and easy to operate, it features replaceable battery and sensor for long-term protection. Designed to offer a low-cost, long-term ownership gas monitoring system.
| Parameter | Specification |
|---|---|
| Detect gas | NO2 |
| Sensor type | Electrochemical |
| Sampling method | Diffusion |
| Measure range | 0-100ppm 0-500ppm |
| Resolution | 0.1ppm |
| Precision | ≤± 3% F.S. |
| Response Time | ≤30s(T90) |
| Unit | PPM %vol lel |
| Display | Gas name, concentration unit, measured value, electricity |
| Alarm mode | Sound, light, vibration alarm, high and low alarm values can be set by user |
| Alarm type | Low alarm, high alarm, STEL, TWA, low battery |
| Display | LCD Display |
| Operating language | Chinese/English |
| Size | 90*60*33mm |
| Weight | 125g |
| Working Temperature | -20ºC~50ºC |
| Working Humidity | 0-95%RH |
| Working air pressure | 86~106kpa |
Established in 2010, Shenzhen Yuan Te Technology Co., Limited (Safegas) specializes in the design, production, and sales of gas detection equipment and systems. With 16 years of industry experience, we provide comprehensive solutions for various sectors including Oil, Chemical, Medicine, Energy, Environmental Protection, Electronics, Municipal Engineering, Agriculture, and Household Appliances.
Our product portfolio includes portable detectors, fixed systems, controller panels and particle counters:
